PEEK5600P Powder

Relying on its previous experience in the PEEK industry, Junhua Medical has entered the polymerization production of PEEK resin, providing more choices and stronger guarantees for domestic PEEK parts and profiles, and creating advantageous conditions for the development of domestic PEEK. At the same time, through customer R&D, production and feedback on profiles and parts, it will also promote the improvement of Junhao’s raw material resin polymerization. As an advanced engineering plastic, PEEK has good machinability, flame retardancy, non-toxicity, wear resistance, corrosion resistance and other properties. It plays an important role in weight reduction, effectively extending the service life of components, and optimizing component utilization. It plays an important role. With the acceleration of downstream application promotion, it is expected that the demand for PEEK in China will further grow in the future and be used in more fields.

Inquire Now
InquiryContact Us
  • PEEK5600P Powder
  • PEEK5600P Powder
Product Detail

PEEK exhibits very superior comprehensive properties because it contains a large number of benzene ring structures in its molecule.

PEEK (polyether ether ketone) resin is a high-performance special thermoplastic material and one of the important varieties of commercial polyaryl ether ketone resins. At present, polyetheretherketone is widely used in petroleum, food processing, automobiles, aerospace and other fields due to its excellent electrical properties, mechanical properties, high temperature resistance, corrosion resistance, etc.

PEEK powder is ground from the coarse powder after PEEK polymerization. According to different grinding processes, powders of different sizes from 200 mesh to 800 mesh can be ground.



Mechanical properties
Item Test Standard or Instrument Unit PEEK5600P
100%PEEK
Tensile strength(23℃) ISO527-2/1B/50 MPa 95
Tensile modulus(23℃) ISO527-2/1B/51 GPa 3.8
Tensile elongation(23℃) ISO527-2/1B/50 % 20
Bending strength(23℃) ISO 178 MPa 152
Bending modulus(23℃) ISO 179 GPa 3.5
Compressive strength(23℃) ISO 604 MPa 128
Lzod impact strength( no gap) ISO 180/U KJ/m² 72
Thermal properties
Item Test Standard or Instrument Unit PEEK5600P
100%PEEK
Melting point DSC 343
Distortion temperature ISO 75-1/-2 163
Continuous using temperature UL 74685 260
Coefficient of ASTM D696 ppm K -1 46
Thermal expansion
Flammable level UL 94 / V-0
Thermal conductivity ISO 22007 W/(m·K) 0.28
Electrical properties
Item Test Standard or Instrument Unit PEEK5600P
100%PEEK
Dielectric strength IEC 60243-1 KV/mm 18
Dielectric constant IEC 60250 3.2
Surface resistance Ω 10₁₃Ω
Lossy medium IEC 60251 0.004
Other properties
Item Test Standard or Instrument Unit PEEK5600P
100%PEEK
Color Natural
Density ISO 1138 g/cm³ 1.3
Water Abs. (25℃.24Hrs) ISO 62 % 0.04
Mould shrinking percentage(25-24℃) 3mm,170℃, Flow direction % 1.2
Perpendicular to flow direction % 1.5
Simeom Denis Poisson ISO 527-2 0.4
Rockwell hardness GB3398.2 HRR 118
Friction coefficient μ 0.30
Melt flow index ISO1133-2005 g/10min 10
PEEK Advantages
